SMC insulates, does not corrode and keeps its shape under heat: that is why it is the usual material for enclosures, switchboards and switchgear. We mould it in series, with integrated machining and cutting, so the part arrives ready to fit on your line.
Dielectric strength of 16 kV/mm, volume resistivity of 1014 Ω·cm and CTI 600 (IEC 60112), with no additional insulating coatings.
Self-extinguishing UL94 V-0 at 3 mm and 960 °C glow-wire resistance at 1.5 mm (IEC 60695-2).
Heat deflection temperature above 250 °C (ISO 75-2) and water absorption below 0.3% (ISO 62).
It does not rust: suitable for outdoor technical cabinets and humid or chemical environments, with no anti-corrosion paint.
7 presses from 150 to 1,250 t, sensor-equipped presses and unit traceability to keep repeatability over long series.
CNC machining of holes and bosses, 5-axis waterjet cutting and in-mould painting when the part needs it.
| Property | Value | Standard |
|---|---|---|
| Dielectric strength | 16 kV/mm | IEC 60243-1 |
| Comparative tracking index | CTI 600 | IEC 60112 |
| Volume resistivity | 1014 Ω·cm | IEC 60093 |
| Surface resistance | 1012 Ω | IEC 60093 |
| Dielectric constant | 4 | IEC 60250 |
| Flammability | V-0 @ 3 mm | UL 94 |
| Glow wire | 960 °C @ 1.5 mm | IEC 60695-2 |
| Heat deflection temperature | > 250 °C | ISO 75-2 |
| Flexural strength | ≥ 190 MPa | ISO 14125 |
| Impact strength (Charpy) | ≥ 85 kJ/m² | ISO 179 |
| Water absorption | < 0.3 % | ISO 62 |
| Density | 1.78 g/cm³ | EN ISO 1183-1 |
Indicative values from the material manufacturer’s datasheet (Astar, Verkid H154, 2025). Product tests (IP, IK rating, etc.) depend on each enclosure’s design and are validated per project.
Yes: our B2B shop offers 2100×1100 mm SMC sheet in quality A (UL94 V-0) and quality B, cut and machined to drawing.
With 7 presses of different tonnage we allocate production according to each mould and cycle time. Share your annual forecast and delivery schedule and we will plan it with you.
Depending on the grade, SMC is supplied in different RAL colours (for example 7035, 9001 or 9002). For a Class A finish, in-mould painting (PIMC).
Yes: our own and customer moulds, with a dedicated store for moulds up to 24 t and their maintenance.
Send us the drawing and annual forecast: we will propose grade, process and price per series, with initial feasibility within 24 working hours.
